Moderate Straight-Through Performance

Introducing Flowmaster's line of FlowFX exhaust systems. These systems are perfect for the person looking for an moderate exterior and interior sound level with all of the performance benefits that you would expect from Flowmaster. New features include bright 409S stainless steel tubing mated to our new FlowFX straight-through mufflers with a large 3.00 inch core for maximum performance and a deep, aggressive sound.

Fitment Information

• Ford Bronco 2.3L/2.7L (2021, 2022, 2023)
• 4 Door Models

Emissions Compliance

This part is legal for sale or use on Emissions Controlled Vehicles, Uncontrolled (Non-Emissions Controlled) Vehicles, and Racing Use Only Vehicles because it does not affect vehicle emissions and is not covered by emissions regulations.

Specs & Features

• Emission Code: 5
• Exit Position: DOR
• Mount Type: Uses New Hangers (Included)
• Muffler Body Length (in): 14
• Muffler Color: Natural
• Muffler Finish: Brushed
• Muffler Inlet Diameter (in): 3.00
• Muffler Inlet Location: Body Side
• Muffler Material:409S Stainless Steel
• Muffler Outlet Diameter (in): 3.00
• Muffler Outlet Location: Dual Outlet
• Muffler Overall Length (in): 25
• Muffler Part Number: Kit Only
• Muffler Quantity: 1
• Muffler Series: FlowFX
• Muffler Shape: Round
• Muffler Type: Absorption
• Sound Level: Moderate/Aggressive
• Tip Cut: Angle
• Tip Diameter: 4.00
• Tip Edge Style: Rolled
• Tip Finish: Black Ceramic
• Tip Length: 5.25
• Tip Logo: Embossed
• Tip Material: 304 Stainless
• Tip Quantity: 2.00
• Tip Shape: Round
• Tip Style: Single Wall
• Tubing Diameter (in): 3.00

Product Description

Flowmaster introduces our Flow FX cat-back exhaust system for the 2021-2023 Ford Bronco with the 2.3 or 2.7-liter engine and 4 doors. This system uses a Flow FX style muffler for a deep exhaust tone with an aggressive to moderate sound level and increased performance. Maximum dyno gains of 12 hp and 13 lb-ft were measured at the rear wheels. 3.00-inch mandrel bent 409 stainless steel tubing is used from the factory mid-pipe flange back to maximize exhaust flow and durability. This step up from the factory pipe size will help maximize gains from additional engine upgrades. The over-axle section is also routed to help gain an additional 2.0-inches of clearance from the axle when used on applications with modified suspensions. This allows for better suspension travel when used in extreme off-road situations. Dual 4.00-inch black ceramic coated tips are used to add a custom look to this iconic vehicle. All of the necessary hardware is included and factory mounting locations are used for an easy installation. Backed by Flowmaster's Lifetime Limited Warranty.

Features:

• Max increases of up to 12 hp and 13 lb-ft over the stock exhaust at the rear wheels
• FlowFX series performance muffler offers a deep powerful sound and increased performance
• 409 stainless steel construction delivers extra durability and improved long-term corrosion resistance
• Uses factory hanger locations for easy installation
• 3.0-inch 16-gauge mandrel bent stainless steel tubing helps maintain maximum exhaust flow for better power
• Includes all necessary hardware for an at home installation
• Dual 4.00-inch black ceramic coated tips adds a custom look
• Lifetime Limited Warranty
