Radium Engineering Remote Mount Fuel Filter (1.5in Vented) 20-1005-V
fuelFitment Information
- Universal
What Includes
- Vented Cap with Roll-Over Protection
- Flanged Fill Neck for 1.5in ID Hose
- Ozone/Flame Resistant Gasket
- Anodized Aluminum Nut Ring
- Stainless Steel M5 Bolts
- Tether Components
Notes:
1. Does not include accessories to connect to the fuel tank.
2. Can be upgraded later to a dry break using Radium 20-0549-V.
Product Description
A remote mounted fuel filler is NOT located directly on the fuel tank or fuel cell, but rather somewhere else on the vehicle, such as the fender.
The fuel filler typically secures to the vehicle body. The vented fuel cap has roll-over protection if the vehicle ever becomes inverted. The fill neck has a machined hose barb connection for 1.5" filler hose. The outer diameter is 4.75" and uses 4.25" P.C.D for the five M5 bolts. Total height is 4.1". Requires a 77mm (3.03") hole to be fabricated.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Radium Engineering Remote Mount Fuel Filter (1.5in Vented) 20-1005-V
Radium Engineering Remote Mount Fuel Filter (1.5in Vented) 20-1005-V
fuelFitment Information
- Universal
What Includes
- Vented Cap with Roll-Over Protection
- Flanged Fill Neck for 1.5in ID Hose
- Ozone/Flame Resistant Gasket
- Anodized Aluminum Nut Ring
- Stainless Steel M5 Bolts
- Tether Components
Notes:
1. Does not include accessories to connect to the fuel tank.
2. Can be upgraded later to a dry break using Radium 20-0549-V.
Product Description
A remote mounted fuel filler is NOT located directly on the fuel tank or fuel cell, but rather somewhere else on the vehicle, such as the fender.
The fuel filler typically secures to the vehicle body. The vented fuel cap has roll-over protection if the vehicle ever becomes inverted. The fill neck has a machined hose barb connection for 1.5" filler hose. The outer diameter is 4.75" and uses 4.25" P.C.D for the five M5 bolts. Total height is 4.1". Requires a 77mm (3.03") hole to be fabricated.
Original: $151.95
-70%$151.95
$45.58Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
fuelFitment Information
- Universal
What Includes
- Vented Cap with Roll-Over Protection
- Flanged Fill Neck for 1.5in ID Hose
- Ozone/Flame Resistant Gasket
- Anodized Aluminum Nut Ring
- Stainless Steel M5 Bolts
- Tether Components
Notes:
1. Does not include accessories to connect to the fuel tank.
2. Can be upgraded later to a dry break using Radium 20-0549-V.
Product Description
A remote mounted fuel filler is NOT located directly on the fuel tank or fuel cell, but rather somewhere else on the vehicle, such as the fender.
The fuel filler typically secures to the vehicle body. The vented fuel cap has roll-over protection if the vehicle ever becomes inverted. The fill neck has a machined hose barb connection for 1.5" filler hose. The outer diameter is 4.75" and uses 4.25" P.C.D for the five M5 bolts. Total height is 4.1". Requires a 77mm (3.03") hole to be fabricated.
